The ultimate oiling solution for high-performance 6.4 Power Stroke builds, our Dry-Sump Kit delivers consistent oil pressure, reduced crankcase pressure, and superior oil control at high RPM and boost levels. This complete system is built for serious racing and extreme engine conditions.
The kit includes a race-proven dry-sump oil pump, custom fabricated pan with scavenging lines, pump brackets, and a high-capacity oil tank with integrated inlet filter. It also comes with a crank mandrel designed for either an ATI or Fluidampr balancer (choose your option at checkout), as well as a vacuum regulator, oil pressure pop-off valve, and our custom oil filter base that accepts a CAT oil filter for maximum filtration and durability.
⚠️ Note: Due to the custom nature of tank and filter placement, you will need to supply your own vacuum-rated line from the pump to the tank, as well as feed and return oil lines. These must be fabricated to fit your specific chassis and layout.
We can quote custom oil and vacuum lines—simply email us with the required lengths and fitting configurations.
